Hardware Characteristics

Descriptions

Model

KB808

Chipset

ASR1803SC

WiFi model

AM802L

WiFi chip

AIC8800DW 2.4G

Power Supply Voltage

Type-C 5V 1A

Power Consumption

Normal Operation Power <3W;

Frequency Band

Europe Version:

FDD LTE: B1/B3/B7 /B8/B20

TDD LTE: B38//B40/B41

WCDMA: B1/B8

Rate

LTE-FDD： Max 150Mbps(DL) Max 50Mbps(UL) LTE-TDD： Max 130Mbps(DL)&nbΩsp;Max 35Mbps(UL) WCDMA: Max 21.6Mbps(DL) Max 5.76Mbps(UL)

WIFI Standard

802.11 ax/b/g/n , 2.4G

LTE Category

Cat4

LED Indicators

Power LEDx1

4G Link LEDx1

LAN LEDx1

Signal Strength LEDx1

Network Interface

1 RJ45 LAN, 10/100Mbps, auto MDI/MDIX

Antenna

2*4G*5DBi, 1*2.4G WiFi*5DBi, 1*Decoration

USIM/SIM

Nano SIM card

ESIM

2 ESIM

Reset Key

Long press 5s to restore the factory default setting

Working Temperature

-10°C－+60°C

Working Humidity

10%－95%RH

Storage Temperature

-30°C－+80°C
